Innovative Power Products is proud to announce its unique online Interactive S-Parameter Viewer! This one-of-a-kind online viewer allows you to scroll, zoom, point and select a sub-band. The viewer, still in beta, adds the flexibility of showing out-of-band data as well as the value at each data point [...]
Innovative Power Products introduces the IPP-7171 surface mount 90-degree hybrid coupler. This 3-port coupler operates from 20 - 1000 MHz with a 25 Watt average power rating. The IPP-7171 comes in a 1.20 x 1.50 inch surface mount package. The IPP-7171 has an amplitude balance of less than 0.75dB, [...]
RF Feedback Resistors for Solid-State Amplifiers IPP’s line of Feedback Resistors are designed to support wideband RF/Microwave solid-state transistor power amplifiers, which require resistive feedback. Using negative resistive feedback is a simple way to improve transistor amplifier stability and frequency gain sloping. These feedback resistors are flange mounted and [...]
Innovative Power Products introduces our model IPP-5014, a 100 Watt surface mount single-ended transformer that operates from 30 – 1000 MHz. The IPP-5014 is a single-ended impedance transformer that operates from 30 to 1000 MHz with a 4:1 transformation ratio and 100 Watt average power rating. The IPP-5014 transforms [...]
Innovative Power Products introduces our latest 90 degree hybrid coupler IPP-7093 that operates over the full 2 – 8 GHz band. Our model IPP-7093 handles 50 watts CW in a Surface Mount package that is only 1.21 x 0.20 x 0.177 inches. The IPP-7093 will combine two signals for [...]
Innovative Power Products introduces our model IPP-3238, a 600 Watt Dual Directional Coupler that operates from 2000 - 8000 MHz. Innovative Power Products, Inc. is proud to introduce one of its newest broadband, high power, Dual Directional Couplers, Model IPP-3238. This is a 600 watt dual directional coupler covering the [...]
Innovative Power Products introduces our model IPP-5004, a 100 Watt surface mount 180° 2-way balun transformer that operates from 30 - 1500 MHz. The IPP-5004 is a unique 3-port Balun that, as a divider, splits an unbalanced input signal at the sum port J1 into a balanced signal output [...]
Innovative Power Products introduces our model IPP-8111, a 150 Watt surface mount Dual Directional Coupler that operates from 2.0 – 6.0 GHz. The IPP-8111 is a unique broadband design which provides separate coupled ports for both forward and reflected signals with internal terminations. This coupler is produced in a [...]
Innovative Power Products introduces our Model IPP-7124, a 150 watt Surface Mount 90 Degree Coupler that operates from 700 - 4200 MHz. Detailed product specifications, including the outline drawing, typical test data, STP file, and s-parameters are available on the product page. The IPP-7124 will combine two signals up [...]
The model IPP-1314 Connectorized Combiner/Divider combines four coherent input signals or divides one signal into four. The IPP-1314 is rated up to 300 Watts CW of total RF input power. This combiner/divider is produced in a 3.08” x 2.60” x 1.03” package with a type N connector on the [...]
Innovative Power Products announces a full line of RF Resistors and Terminations constructed with Aluminum Nitride (AlN) ceramic for low thermal resistance and capacitance. RF Resistors IPP’s high power RF / Microwave Resistor line offers a compact, rugged, high power, high frequency solution to the [...]
The model IPP-1300 combines two coherent input signals or divides one signal into two up to 150 Watts CW of total RF power. This combiner/divider is produced in a 1.5” x 2.5” x 1.03” package with a type N connector on the sum port and SMA connectors on the [...]
Innovative Power Products' model IPP-8090 is now available in a RoHS version. The IPP-8090 is a 200 watt, 32 dB, Surface Mount Dual Directional Coupler that operates from 500 – 3000 MHz. The IPP-8090 is a unique broadband design which provides separate coupled ports for both forward and reflected signals with [...]
Innovative Power Products introduces one of their broadest band 90 Degree SMD Couplers to date, which operates over the full 500 – 6000 MHz. band. Our new Model IPP-7164, handles 100 watts CW and comes in a SMD style package which is only 0.50 x 1.80 x 0.158 [...]
Innovative Power Products offers two High Frequency 90 Degree Surface Mount Coupler models IPP-7112 and IPP-7114. These surface mount couplers are conservatively rated at 50 Watt CW, and operate from 8.0 – 12.0 GHz. and 6.0 – 12.0 GHz. respectively. The IPP-7112 and IPP-7114 product pages list the complete product [...]
Innovative Power Products introduces their latest 90 Degree SMD Coupler that operates over the full 690 – 6000 MHz. band. Our new Model IPP-7148, handles 130 watts CW and comes in a small SMD Style package which is only 0.50 x 1.00 x 0.167 inches. The IPP-7148 will combine two signals [...]
Innovative Power Products introduces their latest “Ultra Broadband” high power 4-Way Combiner/Divider model IPP-1271 which covers the full 700 – 6000 MHz. band. The Model IPP-1271 combines four coherent input signals or divides one signal into four up to 300 Watts CW of total RF power, and is produced in a [...]
Innovative Power Products introduces their new model IPP-8057, a 150 watt, 33 dB, Surface Mount Dual Directional Coupler that operates from 500 – 2500 MHz. The IPP-8057 is a broadband design which provides separate coupled ports for both forward and reflected signals with internal Terminations. This unique coupler is produced in a [...]
Innovative Power Products, Inc. is proud to introduce one of its newest broadband Dual Directional Couplers, Model IPP-3206, a 200 watt Coupler covering 20-520 MHz., in a very small 1.16’’ X 1.76” package with SMA connectors. Insertion loss is <0.40dB, main line VSWR is <1.25:1, coupled flatness is +/-0.60dB and [...]
Innovative Power Products introduces their newest Model IPP-7150. The IPP-7150 is 3dB, 90 degree surface mount hybrid coupler which operates from 2.0 – 6.0 GHz. at 150 watts CW and has improved Amplitude Balance of less than +/- 0.4 dB across the full band. The IPP-7150 will combine two [...]
Innovative Power Products introduces their new Models IPP-2331 and IPP-2332 which operate from 100 – 520 MHz. and handle 400 Watts and 800 Watts respectively. The IPP-2331 and IPP-2332 will combine two signals up to 400 and 800 Watts CW of total output power. These couplers were recently redesigned [...]
IPP-7118 Innovative Power Products introduces their latest 90 Degree coupler that operates over the full 690 – 6000 MHz. band. Our new Model IPP-7118, handles 50 watts CW and comes in a small SMD Style package which is only 0.50 x 1.00 x 0.162 inches. The IPP-7118 will combine [...]
IPP-2315 and 2247 Innovative Power Products introduces their latest 90 Degree coupler that operates over the full 20 – 1000 MHz. band. Our new Model IPP-2315 handles 50 watts CW and comes in a Drop-In Style package which is only 1.71 x 1.90 x 0.76 inches. The IPP-2315 will combine two [...]
Innovative Power Products introduces two new Broadband SMD Dual Directional Couplers Operating from 500 – 2500 MHz. Models IPP-8057, which operates at 50 watts CW and the IPP-8041 which handles 200 watts CW are in small packages and available on Tape & Reel. IPP-8057 Coupling: 33 +/- 1.5 dB [...]
